• Brand / Model: Weichai WP10D264E200

• Gross Power (kWm): ESP 264 / PRP 240

• Cylinders / Type / Aspiration: 6 / In-line / Turbocharged & Aftercooled

• Bore x Stroke (mm): 126 × 130

• Displacement (L): 9.726

• Compression Ratio: 17:1

• Brake Mean Effective Pressure (kPa): ESP 2171

Cooling System

• Coolant Type: Water + 50% antifreeze

• Capacity (L): 35 (with radiator)

• Max Coolant Temp (°C): 105 (shutdown)

• Fan Airflow (m³/min): 415

Lubrication System

• Operating Temp (°C): 78–105

• Oil Consumption Ratio: ≤0.2% of fuel consumption

• System Capacity (L): 30

• Oil Filter: Spin-on full-flow

Fuel System

• Filter: Spin-on type

• Pipe Diameter (mm): Supply 12 / Return 12

• Max Return Restriction (bar): 0.5

• Max Fuel Inlet Temp (°C): 50

• Fuel Supply Flow (L/hr): 169

Fuel Consumption (+3% tolerance):

• 100% ESP → 63.4 L/hr (201.6 g/kWh)

• 100% PRP → 56.9 L/hr (199.1 g/kWh)

• 75% PRP → 42.2 L/hr (197 g/kWh)

• 50% PRP → 28.3 L/hr (198.3 g/kWh)

• 25% PRP → 15.4 L/hr (215.5 g/kWh)

Exhaust System

• Exhaust Temp (°C): 600 (post-turbo)

• Exhaust Flow (m³/min): ESP 50.6 / PRP 46.8

• Max Back Pressure (mbar): 60

Alternator

• Brand / Model: WEICHAI WHA-250-4/0.4 / LEROY-SOMER TAL A46 D

• Rated Current: 361A

• Coupling / Bearing: Direct / Single

• Winding Pitch: 2/3

• Excitation: Self-excited

• Cooling: Air

• Voltage Regulation: AVR

• Insulation: Class H

• Protection Grade: IP23

• Efficiency @ 0.8p.f. 100% load: 92.7% / 91.3%

Control Module

• Back-lit LCD display

• 3-phase generator & mains monitoring

• Monitors: speed, frequency, voltage, current, oil pressure, coolant temp, fuel level

• Displays: warnings, shutdowns, engine status

• Hour counter for maintenance tracking

Standard Conditions

• Ambient Temp: 5°C – 40°C

• Altitude: ≤1000 m

• Humidity: ≤90% (25°C)

• Environment: Clean, free from dust/salt/mold

For extreme or special conditions (humid, salt spray, dusty, high temp, high altitude), consult factory for protective measures.

Dimensions & Weight
