Engine Model: 6BTAA8.3-C215
Gross Power: 160 kW @ 2200 rpm
Operating Weight: 16,800 kg
Powerful Engine: Equipped with a Cummins 6BTAA8.3-C215 engine delivering 160 kW @ 2200 rpm for strong performance.
High Operating Weight: With an operating weight of 16,800 kg, ensuring stability and durability in tough working conditions.
Large Blade Capacity: Designed with a high-capacity moldboard, suitable for heavy-duty grading, leveling, and earthmoving operations.
Enhanced Maneuverability: Features articulated steering and a long wheelbase for improved turning radius and stability.
Operator Comfort: Ergonomically designed cab with wide visibility, reliable controls, and reduced noise levels.
Durable Structure: Built with reinforced frame and heavy-duty components to withstand demanding construction and mining applications.
Operating Weight: 16,800 kg
Engine Model: Cummins 6CTAA8.3-C215
Rated Power: 160 kW (215 HP) @ 2,200 rpm
Displacement: 8.3 L
Max Torque: 980 Nm @ 1,500 rpm
Emission Standard: Euro II / China-II
Wheelbase: 6,560 mm
Travel Speed (Forward): Up to 39.7 km/h
Turning Radius (Outside): 8.2 m
Ground Clearance: 430 mm
Gradeability: 20°
Max Traction Force: 95 kN
Blade Width Options: 3,660 mm / 3,965 mm / 4,270 mm
Moldboard Capacity: Large-capacity moldboard for heavy-duty grading and leveling tasks
Emission Standard:
EURO V
Driving Type:
6X4
Cabin Type:
SITRAK-G7 Cabin, 4-points floating air suspension, air suspension driver seat, with sleeper, with A/C
Seating Capacity:
2
Engine Model:
MC13.48-50
Engine Type:
6 cylinders in line, 4 strokes common rail diesel engine, water cooling, Intercooler Turbocharged, with EVB
Powered by a 480 HP Euro V engine with 2300 N·m torque for strong performance.
Equipped with a 12-speed AMT transmission for smooth and efficient driving.
Built with durable axles and high-strength frame for heavy-duty operations.
Features an air-suspended cabin with dual sleepers and A/C for driver comfort.
Enhanced with advanced braking and safety systems for reliable long-haul transport.
