Powered by a 480 HP Euro V engine with 2300 N·m torque for strong performance.
Equipped with a 12-speed AMT transmission for smooth and efficient driving.
Built with durable axles and high-strength frame for heavy-duty operations.
Features an air-suspended cabin with dual sleepers and A/C for driver comfort.
Enhanced with advanced braking and safety systems for reliable long-haul transport.
Powerful & Efficient Engine
Equipped with the MC13.48-50 Euro V engine delivering 480 HP and 2300 N·m torque, ensuring strong performance and compliance with modern emission standards.
Advanced AMT Transmission
Features a 12-speed AMT gearbox with optional PTO, offering smooth gear shifts, reduced driver fatigue, and optimal fuel efficiency.
Heavy-Duty Axles
Front axle (7 t capacity) with disc brakes.
Rear axle (13 t capacity) with disc brakes and multiple ratio options for versatile applications.
Comfortable & Safe Cabin
SITRAK-G cabin with 4-point floating air suspension.
Air suspension driver seat, dual sleeper bunks, A/C, and driver airbag.
Enhanced visibility and reduced noise for a better driving experience.
High Safety Standards
Equipped with ABS, EBS, ESC, AEB, LDW, HSA, and ADR system for maximum operational safety.
Robust Suspension System
Reinforced leaf spring front suspension.
Air suspension rear for stability, load adaptability, and driver comfort.
Durability & Reliability
Built with a TGA high-strength single-layer frame.
Fitted with JOST 50# fifth wheel (2-inch kingpin) for reliable trailer coupling.
Efficiency & Range
Large 600 L aluminum fuel tank for extended operations.
Maximum speed limited to 90 km/h with excellent gradability (30%) for tough routes.
Electrical & Safety Systems
24V system with 180 Ah batteries, high-capacity alternator, and starter.
Integrated spark arrestor for safe operations in sensitive environments.
Cabin
SITRAK-G new Cabin
4-points floating air suspension
Air suspension driver seat
Two sleepers, with A/C
Driver airbag
Seating capacity: 2
Engine
Model: MC13.48-50
Type: 6 cylinders in-line, 4 strokes, common rail diesel engine
Cooling: Water cooling, Intercooler Turbocharged
Displacement: 12,419 cc
Bore × Stroke: 126 × 166 mm
Max. Power: 480 HP (353 kW) @ 1900 rpm
Max. Torque: 2300 N·m @ 1050–1400 rpm
Transmission
Model: SINOTRUK HW25712XACL AMT gearbox
Type: 12F + 1R AMT transmission, optional PTO
Clutch: Electrically operating with air assist, Dia: 430 mm
Ratios:
Forward: 11.80 / 9.17 / 7.10 / 5.61 / 4.38 / 3.44 / 2.70 / 2.10 / 1.62 / 1.28 / 1.00 / 0.79
Reverse: 10.85
Max. Torque: 2500 N·m
Front Axle
Model: VPD71DS
Load Capacity: 7000 kg
Brake Type: Disc brake with self-adjusting arm, maintenance-free axle
Rear Axle
Model: MCY13JES
Load Capacity: 13,000 kg
Ratio: 3.70 (optional: 3.08, 4.11)
Brake Type: Disc brake with self-adjusting arm, single reduction
Suspension
Front: Reinforced leaf spring (3 pieces)
Rear: Air suspension
Steering
Power steering, BOSCH steering gearbox
Chassis
Frame: TGA frame, single layer (8/280 mm)
Wheels & Tires
315/80R22.5, 6+1 pcs
Optional: TPMS
Fifth Wheel
Model: JOST 50
Kingpin Size: 2 inch
Electrical System
Working voltage: 24V, negative grounded
Alternator: 24V, 7.5 kW, 3-phase
Starter: 24V, 3 kW
Batteries: 2 × 12V – 180 A.H
Braking & Safety Systems
ABS: EBS + ESC
Safety Assistance: AEB + LDW + HSA, ADR system included
Dimensions & Weights
Overall: 6400 × 2550 × 3850 mm (approx.)
Wheelbase: 3900 mm
Wheel Track: 2055 mm (front) / 1850 mm (rear)
Overhang: 1475 mm (front) / 725 mm (rear)
Approach/Departure Angle: 23° / 65°
Curb Weight: ~7800 kg
GCW: 45,000 kg
Max Speed: 90 km/h (limited)
Max Gradability: 30%
Min Ground Clearance: 280 mm
Fuel Tank
600 L Aluminium fuel tank
Other
Exhaust pipe in front with spark arrestor
Emission Standard:
EURO V
Driving Type:
6X4
Cabin Type:
SITRAK-G7 Cabin, 4-points floating air suspension, air suspension driver seat, with sleeper, with A/C
Seating Capacity:
2
Engine Model:
MC13.48-50
Engine Type:
6 cylinders in line, 4 strokes common rail diesel engine, water cooling, Intercooler Turbocharged, with EVB
