Emission standard: EURO V
Driving type: 6×6
G7-F Cabin, 4-points floating air suspension
Mechanic co-driver seat, air suspension driver seat, with sleeper
Seating capacity: 2
Model: MC13.54-30, 540hp, Euro 5
Type: 6 cylinders in line, 4 strokes common rail diesel engine, water cooling, Intercooler Turbocharged
Displacement: 12,419 cc
Bore × stroke: 126 × 166 mm
Max. power: 540HP (397KW) @ 1900 rpm
Max. torque: 2500 N.m @ 1050–1400 rpm
Key Features – SITRAK 6x6 Prime Mover
High Power and Performance:
Equipped with the MC13.54-30 engine delivering 540 HP (397 kW) and a maximum torque of 2500 N·m for exceptional pulling power.
Durable Drivetrain:
ZF16S2530TO transmission with 16 forward and 2 reverse gears, paired with a G253P32 transfer case, ensuring efficiency and reliability.
Heavy-Duty Axles:
Front axle capacity of 9000 kg and twin rear axles with 2 × 13,000 kg capacity, both with drum brakes and self-adjusting arms.
Superior Suspension and Frame Strength:
Leaf spring suspension (3 front / 11 rear) with a single-layer frame (10/270) designed for stability and durability.
Enhanced Driver Comfort:
G7-F cabin with 4-point floating air suspension, air suspension driver seat, sleeper berth, and A/C system.
Safety and Control:
Equipped with ABS brake system (4S/4M), intelligent braking, and vertical exhaust system for safe operation.
Robust Off-Road Capability:
6×6 drive, 33° approach / 62° departure angles, and 45% gradability for extreme terrain.
Extended Operating Range:
600 L fuel tank capacity supports long-distance heavy-duty transport.
Model series: SITRAK-C7H
Emission standard: EURO V
Driving type: 6×6
G7-F Cabin, 4-points floating air suspension
Mechanic co-driver seat, air suspension driver seat, with sleeper
Seating capacity: 2
Model: MC13.54-30, 540hp, Euro 5
Type: 6 cylinders in line, 4 strokes common rail diesel engine, water cooling, Intercooler Turbocharged
Displacement: 12,419 cc
Bore × stroke: 126 × 166 mm
Max. power: 540HP (397KW) @ 1900 rpm
Max. torque: 2500 N.m @ 1050–1400 rpm
Exhaust system: Vertical exhaust pipe
Hydraulically operating with air assistance
Diameter: 430 mm
Model: ZF16S2530TO
Gear numbers: 16F + 2R
Ratio:
F: 13.8, 11.54, 9.49, 7.93, 6.53, 5.46, 4.57, 3.82, 3.02, 2.53, 2.08, 1.74, 1.43, 1.2, 1.00, 0.84
R: 12.92, 10.8
Max torque: 2200 N.m
PTO model: NH1/b flange type PTO
Model: G253P32
Ratio: 0.981 / 1.583
Front Axle Model / Load Capacity: MVP09 / 9000 kg, Ratio: 6.0
Brake type (Front): Drum brake with self-adjusting arm
Rear Axle Model / Load Capacity: MCP16 / 13000 × 2 kg, Ratio: 6.0
Brake type (Rear): Drum brake with self-adjusting arm
Front / Rear: Leaf spring, 3 pieces / 11 pieces
Power steering
Size: Single layer frame (10/270)
Type/No.: 525/65R20.5 / 6+1
Model & Kingpin size: 90# JOST / 3.5’
Working voltage: 24V, negative grounded
Alternator / Battery: 24V, 7.5kw / 3-phase, 24V, 3KW / 2×12V-180A.H
ABS Brake system: ABS (4S/4M), Intelligent C system
Overall (L × W × H): 7492 × 2550 × 3405 mm
Wheelbase: 3900 + 1400 mm
Wheel track (front/rear): 2248 / 1944 mm
Overhang (Front/Rear): 1475 / 700 mm
Approach/Departure angle: 33° / 62°
Curb weight: 13,000 kg
GVW: 35,000 kg
Max speed: 75 km/h
Max gradability: 45%
Min turning radius: 10.5 m
Min ground clearance: 348 mm
Fuel tank capacity: 600 L
